Parts 068 – Horse Power Ignition

Rotor

Name

Description

068R030

Wallaroo

A: 14.20mm

B: 8mm

C: 5.7°

D: -

E: -

F: -

068R031

Piaggio

A: 16.00mm

B: 10mm

C: 5.7°

D: -

E: -

F: -

068R032

Minarelli

A: 15.20mm

B: 6mm

C: 5.7°

D: -

E: -

F: -

068R034

Puch Maxi

A: 16.25mm

B: -

C: 5.7°

D: -

E: -

F: 11.42mm

068R035

NSR

A: 20.15mm

B: -

C: 5.7°

D: -

E: -

F: 15.31mm

068R036

Suzuki

A: 17.55mm

B: -

C: 5.7°

D: -

E: -

F: 12.00mm

068R037

A: 18.60mm

B: -

C: 5.7°

D: -

E: -

F: 13.56mm

068R038

KTM

A: 18.80mm

B: -

C: 4.0°

D: -

E: -

F: 15.19mm

068R060

Bultaco

A: 22.00mm

B: -

C: 4.0°

D: -

E: -

F: 18.56mm

068R061

Street Magic

A: 17.05mm

B: -

C: 5.7°

D: -

E: -

F: 12.07mm

068R077

A: 15.40mm

B: -

C: 5.7°

D: -

E: -

F: 11.32mm

068R078

Aprilia RS

A: 21.25mm

B: -

C: 5.7°

D: -

E: -

F: 16.20mm

068R079

BSA

A: 19.00mm

B: -

C: -

D: -

E: -

F: -

068R122

CB72

A: 21.90mm

B: -

C: 5.7°

D: -

E: -

F: 17.16mm

068R142

XR75

A: 17.05mm

B: -

C: 5.7°

D: 9.00m

E: 17.10

F: 12.07mm

068R145

CB750

A: 24.00mm

B: -

C: 5.7°

D: -

E: -

F: 18.89mm

068R147

A1R

A: 20.00mm

B: -

C: -

D: -

E: -

F: -

068R149

Husqvarna 250

A: 17.00mm

B: -

C: 4.0°

D: -

E: -

F: 13.57mm

068R150

Maico Big

A: 21.00mm

B: -

C: 4.0°

D: -

E: -

F: 17.12mm

068R170

Maico Small

A: 20.00mm

B: -

C: 4.0°

D: -

E: -

F: 16.27mm

068R218

Ciao

A: 17.00mm

B: -

C: 5.7°

D: 4.5mm

E: 33mm

F: 11.92mm

068R225

CB500

A: 19.20mm

B: -

C: 5.7°

D: -

E: -

F: 14.00mm

068R234

MBK

A: 15.10mm

B: -

C: 3.0°

D: -

E: -

F: 12.19mm

068R246

TZR250

A: 23.20mm

B: -

C: 5.7°

D: -

E: -

F: 18.37mm

068R317

Montesa

A: 21.60mm

B: -

C: 3.0°

D: -

E: -

F: 18.50mm

068R327

Tiger Cub 1

A: 15.85mm

B: -

C: -

D: -

E: -

F: -

068R328

Tiger Cub 2 with keyway

A: 19.00mm

B: -

C: -

D: -

E: -

F: -

068R351

CZ 360

A: 24.00mm

B: -

C: 3.0°

D: -

E: -

F: -

068R357

Husqvarna 430

A: 17.90mm

B: -

C: 4.0°

D: -

E: -

F: 14.19mm

068R400

TZ750

A: 17.00mm

B: -

C: -

D: -

E: -

F: -

Stator

Name

Description

068S100B

360ohm | 360° | ---- (Black, Low stack)

068S100B-H

360ohm | 360° | ---- (Black, High stack)

068S100R

360ohm | 360° | ----

068S109B

360ohm | 360° | BSA (Black, Low stack)

068S109B-H

360ohm | 360° | BSA (Black, High stack)

068S174B

360ohm | 360° | XR250 (Black, Low stack)

068S190B

360ohm | 360° | Ø90 (Black, Low stack)

068S190B-H

360ohm | 360° | Ø90 (Black, High stack)

068S190R

360ohm | 360° | Ø90

068S194B

360ohm | 360° | Ø94 (Black, Low stack)

068S194B-H

360ohm | 360° | Ø94 (Black, High stack)

068S194R

360ohm | 360° | Ø94

068S200B

360ohm | 180° | ----

068S209B-H

360ohm | 360° | BMW (Black, High stack)

068S219R

360ohm | 360° | Ciao (Ø70 to 89,5)

068S229B

360ohm | 180° | TZR250 (Ø65 to 70)

068S258B

360ohm | 360° | Universal direct Ø110 low plate (Black, Low stack)

068S258B-H

360ohm | 360° | Universal direct Ø110 low plate (Black, High stack)

068S289B

360ohm | 360° | Universal direct Ø108 (Black, Low stack)

068S290B

360ohm | 180° | Ø90

068S294B

360ohm | 180° | Ø94

068S300B

360ohm | 120° | ----

068S303B

360ohm | 180° | Ø130

068S316B

360ohm | 180° | Benelli (Ø94 to 93)

068S318B

360ohm | 120° | GT750 (RH)

068S329B

360ohm | 360° | Tiger Cub (Black, Low stack)

068S390B

360ohm | 120° | Ø90

068S391B

360ohm | 360° | Universal direct Ø110 low plate (Black, Low stack, Narrow)

068S394B

360ohm | 120° | Ø94

068S424B

360ohm | 360° | Universal direct Ø115 (Black, Low stack)

068S434B

360ohm | 360° | Universal direct Ø110 high plate (Black, Low stack)

068S434B-H

360ohm | 360° | Universal direct Ø110 high plate (Black, High stack)

068S455R

180° | Honda CR (Red, Low stack)

068S455RH

180° | Honda CR (Red, High stack)

068S458B

360ohm | 360° | Universal direct Ø130 (Black, Low stack)

068S458B-H

360ohm | 360° | Universal direct Ø130 (Black, High stack)

068S459B

360ohm | 360° | direct Ø110 SEM (Black, Low stack)

068S489B

360ohm | 360° | —

068S890Y

80ohm | 360° | Ø90 | (Yellow, Low stack)

068S894Y

80ohm | 360° | Ø94 | (Yellow, Low stack)

CDI-units

Name

Description

068C002

Analogue CDI - Curve 002

068C041

Digital CDI - 4 stroke

068C042

Digital CDI - 2 stroke

068C042RS125

Digital CDI - 2 stroke - special made for Honda RS 125 This kit has standard a tacho exit

068C068

Analogue CDI - Curve 068

068C106

Analogue CDI - C068 curve - 2 HT exits

068C107

Digital CDI - 2 stroke - 2 HT exits

068C108

Digital CDI - 4 stroke - 2 HT exits

068C130

2/3/4 Cylinder 2 Stroke - Analogue

068C130B

Analogue CDI - Curve 210

068C165

Digital CDI - 1 cylinder - 4 Stroke w. Adjustable Rev-Limiter

068C206

Analogue CDI - C130 curve - 2 HT exits

068C207

Digital CDI - 2 stroke - 2 HT exits

068C208

Digital CDI - 4 stroke - 2 HT exits

068C241

Digital CDI - 4 stroke

068C242

Digital CDI - 2 stroke

068C265

Digital CDI - 2 cylinder - 4 Stroke w. Adjustable Rev-Limiter

068C297

Analogue CDI - Curve 297

068C341

Digital CDI - 4 stroke

068C342

Digital CDI - 2 stroke

068C842

Digital CDI 80 Ohm

068C880

Analogue CDI 80 Ohm

Baseplate

Name

Description

068B001

PitBike

068B003

CB750

068B018

NSR / MTX

068B019

Minarelli

068B020

Wallaroo

068B021

Piaggio 50

068B022

Universal Ø110 multi

068B046

Universal Ø110

068B054

CB750K

068B065

Universal Ø130 high

068B073

Universal Ø120

068B074

Morini 50 (Wallaroo + bus)

068B080

Aprilia RS / Gilera GPZ125

068B081

Universal Ø108

068B082

Piaggio 125

068B083

XS650 (Ø130)

068B087

GT550/GT750 (Left Hand Fitting)

068B090

Universal Ø105

068B091

CR250R

068B103

Universal Ø130

068B105

Mito 125

068B114

KTM 250SX

068B120

KX125 (Ø115)

068B123

CB72

068B125

CRF100

068B136

XL75

068B151

KTM 250MX

068B161

RD350 (Ø130)

068B162

CB350

068B163

CB450

068B164

TZ250

068B166

TT (Ø140)

068B169

Maico High

068B175

Camino

068B212

GS1000

068B213

Z1000

068B217

Bultaco (NSR to 110)

068B220

CB500

068B224

Aermacchi

068B226

CB400F

068B230

RD500

068B232

Italjet

068B237

Morini 125

068B239

Morini 175

068B243

KTM 65SX

068B245

RT125

068B248

Puch MX125

068B259

CZ 360

068B269

TZ500

068B275

MBK

068B287

CR80

068B293

Lambretta 175

068B321

XT250

068B334

Minarelli Low

068B353

Lambretta GP

068B358

Husqvarna

068B398

TZR250

068B399

TZ750

068B409

Maico Low

068B418

XS250

068B420

TRX250

068B422

Suzuki 100-125cc 73-76 Ø115

068B423

Yamaha 490

068B449

KLX250 (Ø110)

068B476

Husqvarna CR 125 2007-2013 Husqvarna WR 125 2007-2013

068B480

CR250

Other parts

Name

Description

068M361

3x M5 x 15mm sunken

068M362

2x M5 x 15mm

068M363

3x M8 x 45mm

068V005

Fan adaptor plate Wallaroo

068V007

HT-coil 2 exits

068V023

Fan adaptor plate Minarelli

068V024

Light coil for innerrotor type 10W 2004

068V043

Interface and software for all digital HPI CDI's

TO Donwload the software CLICK HERE

068V064

Switchbutton (for 2 curves selection)

068V075

Fan adaptor plate universal

068V088

Honda fillring

068V092

Rotor adaptor GT750 (LH) + screw

068V101

Inertia disc, 300 grams, RVS

068V171

Rotor adaptor GT250 (+21mm)

068V178

Rotor aligner XR250

068V179

Extension cord (30 cm)

068V180

Divarication for Pitsch Kröber RN22 rev-counters

068V182

Y-Branch for killswitch - 2 cylinder

068V183

Y-Branch for killswitch - 3 cylinder

068V184

Igntion mounting kit

068V185

Y-Branch for YPVS engines

068V186

HT-coil 1 exit - black

068V235

Y-Branch for AETC engines

068V262

Flywheel puller

068V270

Stator adaptor Ø94 +5mm (shim - to raise the stator)

068V301

Kill switch

068V302

Stator adaptor Ø94 +16.5mm (shim - to raise the stator)

068V309

Spark Plug Cap, 0 ohm (Black)

068V310

Spark Plug Cap , 5Kohm (Black)

068V311

Spark Plug Cap , 5Kohm (Red)

068V325

Rotor adaptor Triumph Tiger Cub

068V330

HTCDI1

068V332

Y-Branch for 2 curve switch - 2 cylinder

068V333

Y-Branch for 2 curve switch - 3 cylinder

068V436

Curve switch extension cord (60 cm)

068V438

HT-coil mounting kit

068V439

Rotor filler ring

068V446

Light switch

068V469

HT extention cord

068V470

Universal fan for 068 flywheel

068V478

Inertia disc, 600 grams, RVS Ø110mm Thickness 9mm
